EES-X-144
Complete Ethanol Extraction System
Turn Key Extraction Systems
Compact yet powerful, the MACH Technologies EES-X-144 is tailored for efficient extraction needs, handling up to 80 lbs per 8-hour shift. This automated, user-friendly system features superior USA engineering, plug-and-play installation, advanced safety interlocks, specialized O-ring sealing, and integrated remote support—making it perfect for consistent, high-quality extraction with minimal operational costs.
Product Specifications (EES-X-144)
| Capacity Per Shift | 80 |
|---|---|
| Capacity Per Day | 144 |
| Batch Time | Typically between 10-15 minutes, dependent on recipe |
| Features | Automated, single HMI controlled system from biomass to winterized, decarboxylated crude or distillate |
Fully Automated and Integrated Botanical Extraction
The MACH Technologies EES Series is a complete, PLC controlled, automated cold ethanol extraction system which includes continuous ethanol chilling and pumping, extraction, integrated recirculation, particle filtration, solvent recovery with automated discharge of the recovered ethanol and concentrated oil, and decarboxylation. The entire system is controlled from a single operator interface and provides precision temperature and process controls with automated valving controlled by the MACH proprietary, recipe driven control system
One Interface,
Total Ethanol Extraction Automation
Complete process from ethanol chilling, extraction, recirculation, and filtration is controlled by a single operator interface.
Single Operator
The entire skid is controlled through a single operator interface
Superior Engineering
The entire system was designed by our USA engineering team, who has 40+ years of expertise in chemical, mechanical and controls engineering.
USA Manufacturing
This entire system was manufactured in our USA facility, which guarantees the quality.
Safety
The system incorporated the latest in safety controls and interlocks, for safe operation
Jacketed Vessel
The extraction unit has a double jacket for cooling and vacuum insulation, to maximize efficiencies and lower operational costs
C1D2
The machine & components are designed for C1D2 environments
Plug & Play
The machine has plug and play electrical connections for quick installation and trouble-free startup
Easy to Use
The entire system is controlled via a single operator interface and incorporated automated controls
On-Demand Support
The machine incorporated a remote connection, for on demand technical support from the MACH technical team
Specialized O-Ring Sealing System
The unit has a cascade o ring sealing system to ensure leak free operation
Lower Operational Cost
The machine is designed for efficiencies to reduce the operational costs, such as double tank jackets, insulated piping, motor amperage monitoring system, and electrical cooling
Support & Spare Parts
MACH Technologies has a dedicated spare parts team, and stocks spare parts for quick, same day shipment
